PCB Design & Electronics

Hardware that works — down to the trace.

From first schematic to tested board. MPRO9 handles the full pipeline: design, development, prototyping, and integration for electronics that ship.

Start a Project View Our Work

What We Deliver

Four disciplines.
One complete pipeline.

PCB Design & Layout

Custom schematics and multi-layer board layouts engineered for signal integrity, thermal management, and clean design-for-manufacture. Single-layer through 8-layer, controlled impedance, RF-aware routing.

Design Rule Check Up to 8 Layers

Circuit Development

Component selection, schematic validation, simulation, and BOM generation. Power supply design, sensor interfacing, analog front-ends, and mixed-signal layout for demanding environments.

Simulation Verified SPICE + LTspice

Electronics Prototyping

Rapid hardware prototypes, hand-assembled or pick-and-place, for functional validation before production. Fast iteration from first board spin to verified bring-up.

Rapid Turnaround 48hr First Article

Testing & Integration

Functional bring-up, boundary scan, firmware flash, and integration with mechanical and software systems. Every board leaves verified against the specification.

Firmware + Hardware IPC Class 2 / 3

Layer Architecture

Every layer
engineered.

Multi-layer boards are more than stacked copper. Each layer is a functional domain: signal routing, power distribution, ground planes. We design them as a system.

  • Silkscreen overlay
  • Solder mask
  • Top copper — L1
  • FR4 core substrate
  • Ground plane — L2

Design Complexity

Precision at every
millimetre.

Modern electronics pack remarkable density into small spaces — fine-pitch FPC connectors, high-speed differential pairs, multi-layer stackups, and thermal management all competing for the same real estate.

This is the level of layout complexity we design for. Dense routing, sensor interfacing, tight tolerances — that is exactly where we work best.

Discuss Your Project

Process

From concept
to tested board.

Six stages. No shortcuts.

Schematic
Requirements to validated circuit
Layout
Placement and trace routing
DRC
Design rule check and sign-off
Fabrication
Bare board manufacture
Assembly
Component placement and solder
Bring-up
Firmware, testing, integration
Circuit Design We design your circuit from scratch — schematic capture, component selection, and layout planning to your specification.
PCB Layout Multi-layer board layout with copper pours, trace routing, and DRC-clean files ready for fabrication.
Fab Coordination We send your design files to manufacturers we know and trust, and specify the quality standards they must meet.
Board Delivery Manufactured PCBs delivered to you, verified and ready for assembly or integration into your product.

Get Started

Ready to build
your next board?

Send your requirements — schematic, concept, or rough spec — and we scope the project within 24 hours.

Start a PCB Project View Our Portfolio
